Sun readable high brightness;
Slim bezel commercial display panel;
Wide Operating Temperature Range;
Smart Brightness Control;
21.5inch LCD panel with 1920x1080 resolution;
Screen brightenss up to 2500cd/m2;
Ambient light sensor auto adjust screen brightness;
Support 7*24 hours long time playback;
Android OS operating system;
Bluetooth and WIFI enabled;
4 locking caster wheels;
Remote access monitoring for display status;
Model | LSD185-Q | LSD215-Q | LSD238-Q | LSD270-Q |
Size | 18.5" | 21.5" | 23.8" | 27" |
Panel Technology | IPS (RGB) | IPS(RGB) | IPS(RGB) | IPS(RGB) |
Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 |
Resolution | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 |
Brightness | 2000nits | 2000nits | 2000nits | 2000nits |
Contrast | 1200:1 | 1200:1 | 1200:1 | 1200:1 |
Viewing Angle | 178/178 | 178/178 | 178/178 | 178/178 |
Surface Treatment | Haze 3% | Haze 3% | Haze 3% | Haze 3% |
Life Time | 50000Hrs | 50000Hrs | 50000Hrs | 50000Hrs |
Working Time | 7*24Hrs | 7*24Hrs | 7*24Hrs | 7*24Hrs |
Display Mode | Support Landscape & Portrait | Support Landscape & Portrait | Support Landscape & Portrait | Support Landscape & Portrait |
Specification | A133 1+16GB or 3566 2+16GB | |||
Interface | RJ45*1 USB*1 DC12V | |||
Color | Black/White | Black | Black | Black |
Border Dimension | 15mm | 15mm | 15mm | 15mm |
Unit Dimension | 440*272*40mm | 510*302*40mm | 559*328*40mm | 630*368*40mm |
N.W. | 3kg | 4kg | 5kg | 6kg |
Installation Way | Ceiling mounted | Ceiling mounted | Ceiling mounted | Ceiling mounted |
Working Temperature | 0--40 degree | 0--40 degree | 0--40 degree | 0--40 degree |
Working Humidity | 10%--85% | 10%--85% | 10%--85% | 10%--85% |
Input Voltage | 180-264V, 50/60Hz | 180-264V, 50/60Hz | 180-264V, 50/60Hz | 180-264V, 50/60Hz |
Max Power Consumption | 56W | 68W | 66W | 80W |
